Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Application | Data Acquisition, Energy Management, Industrial Automation, Remote Monitoring |
| Connection to Host | Backplane |
| Controller Type | Communication |
| Depth | 0.197" (5mm) |
| Dimensions | 82.55 x 18.29 x 69.85 mm |
| For Use With | SNAP PAC System |
| Input Current | 250 mA |
| Isolation Voltage | 750 VAC |
| Length | 3.25" (82.55mm) |
| Maximum Operating Temperature | 70 C |
| Minimum Operating Temperature | 0 C |
| Module Type | Serial Communication |
| Mounting Type | Rack |
| Number of Channels | 2 |
| Number of I/O Ports | 2 |
| Output Type | Analog |
| Primary Type | Control |
| Product Header | Serial Communication Module |
| Series | |
| Special Features | Individually Isolated Ports |
| Standards | CE Marked |
| Supply Voltage | 5 VDC |
| Temperature Operating Range | 0 to 70 C |
| Type | Communication |
| Width | 0.72" (18.29mm) |
Overview
SNAP Serial Communication Modules interface with serial-based devices and are designed for users of SNAP PAC systems and legacy Ethernet-based SNAP systems. Multiple serial products are supported. SNAP-SCM-232 and SNAP-SCM-485-422 modules provide two channels of RS-232 or RS-422/485 serial data. The SNAP-SCM-W2 module provides two channels of Wiegand-format serial data input, and the SNAP-SCM-PROFI module provides a standard high-speed interface to PROFIBUS DP® networks.
