Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | MCR-FL-C-UI-2UI-DCI-NC |
| Current Rating | 25 A |
| Input Type | Current, Voltage |
| Input, Range | 0 to 12, 0 to 24 V, mA |
| Maximum Operating Temperature | 55 °C |
| Minimum Operating Temperature | -20 °C |
| Module Type | Conditioner |
| Mounting Type | DIN Rail |
| Number of Channels | 2 |
| Output Type | Current, Voltage |
| Series | |
| Special Features | 4-way isolation, Calibrated selectable input & output signals, Configurable Inputs & Outputs Signal Conversion & Amplification |
| Standards | CE Compliant, UL, USA⁄Canada |
| Supply Voltage | 20 to 30 VDC |
| Temperature Operating Range | -20 to 55 °C |
| Termination | Screw Terminals |
| Type | Signal Converter |
| UPC Code | 4017918820336 |
Overview
Phoenix Contact MCR Series – MINI Analog highly compact signal conditioners:
Maximum signal quality with minimal space requirements – MINI Analog signal conditioners isolate, convert, filter, and amplify your analog signals – with a design width of just 6.2 mm. The configurable MINI Analog modules are easy to set with DIP switches – without the need for any software. Alternatively, Phoenix Contact can make the settings based on your individual ordering information.
Features:
For enhanced functionality and monitoring, you can also configure the modules with the robust S-Port interface conveniently using a free-of-charge software interface. Here you can choose between three solutions:
1. Standalone ANALOG -CONF software
2. FDT/DTM software package
3. Standalone DTMs, allowing you to use your existing FDT frame application
